SC8 Technical Specifications
Product model SC 8
OS Android 14
Processor Octa-Core 2.2GHz
Memory 4GB RAM+32GB ROM 8GB RAM+64GB ROM(※)
Display Main screen 15.6-inch Secondary screen 10.1-inch or 15.6-inch(※)
Touch 10-Point G+G Touch
Printer 80mm printer with cutter, Print speed 250mm/s(max)
Network LAN 10M/100M/1000M
Wi-Fi 2.4GHz & 5GHz IEEE 802.11 a/b/g/n/ac supported
Bluetooth BT 5.4
I/O Ports 6*USB, 1*RJ45, 1*RJ12,1*DB9,1*DC
Audio Digital Audio Speaker
Power DC 12V/3A
NFC(※) ISO14443 Type A/B,MIFARE NFC used two ways: 1. Beside the device； 2. Under second Display
MSR(※) ISO7812,IBM,AAMVA,JIS-2 and other
Camera (※) Monocular / Binocular
Scanner (※) 1D & 2D Code
Operation Environment Working temperature: 0℃-45℃ Operation humidity: 20%-80%
Storage Environment Storage temperature: -10℃~50℃ Storage humidity: 20%-80%
Dimensions 381mm(L)*190mm(W)*385mm(H)

※ Optional: This symbol indicates that the corresponding feature, component, or service is optional and not included in the standard product configuration.

Product model SC 8
OS Windows 10
Processor J6412 i3 or i5(※)
Memory 4GB RAM+128GB ROM 8GB RAM+256GB ROM(※) 16GB RAM+512GB ROM(※)
Display Main screen 15.6-inch Secondary screen 10.1-inch or 15.6-inch(※)
Touch 10-Point G+G Touch
Printer 80mm printer with cutter, Print speed 250mm/s(max)
Network LAN 10M/100M/1000M
Wi-Fi 2.4GHz + 5GHz(※) IEEE 802.11 a/b/g/n/ac supported
I/O Ports 4*USB, 1*RJ45, 1*HDMI,1*DB9,1*DC,1*3.5MM AUDIO
Audio Digital Audio Speaker
Power DC 12V/7A
NFC(※) ISO14443 Type A/B,MIFARE NFC used two ways: 1. Beside the device； 2. Under second Display
MSR(※) ISO7812,IBM,AAMVA,JIS-2 and other
Camera (※) Monocular / Binocular
Scanner (※) 1D & 2D Code
Operation Environment Working temperature: 0℃-45℃ Operation humidity: 20%-80%
Storage Environment Storage temperature: -10℃~50℃ Storage humidity: 20%-80%
Dimensions 381mm(L)*190mm(W)*385mm(H)

※ Optional: This symbol indicates that the corresponding feature, component, or service is optional and not included in the standard product configuration.

1. In case of any discrepancy between the actual usage data and the above data, the actual usage data shall prevail.
2. The product information on this page may be updated periodically due to product upgrades or other reasons. SUNTEK reserves the right to modify the product information and content on this website without prior notice.
3. SUNTEK places great emphasis on safeguarding your personal information and privacy. Protecting the operational data of each device is also our top priority in product design. For more details, please refer to the SUNTEK Privacy Statement and Terms of Service.
